SAVX N-Type TOPCON Series 200 Watt Monocrystalline Solar Panel

(1 customer review)

Original price was: 7,000.00৳ .Current price is: 6,400.00৳ .

🔥 SAVX N-Type TOPCON 200 Watt Monocrystalline Solar Panel

Specification Details
Model SAVX-200-12M10
Type N-Type TOPCON  Monocrystalline Solar Panel
Power Rating 200 Watts
Series N Series
Warranty 25 Years Performance Warranty
Add to wishlist
11 People watching this product now!
5
1 review
1
0
0
0
0

1 review for SAVX N-Type TOPCON Series 200 Watt Monocrystalline Solar Panel

Clear filters

  1. মুসা মিয়া –

    কবে আসবে পেনেল টা একটা লাগবে

Add a review

Your email address will not be published. Required fields are marked *

You have to be logged in to be able to add photos to your review.

🔌 Electrical Data

Parameter Value
Module Type SAVX-200-12M10
Nominal Peak Power (Pmax) 200 W
Minimum Power Tolerance (ΔPmax) ±3%
Maximum Power Voltage (Vmp) 19.0 V
Maximum Power Current (Imp) 10.53 A
Open-circuit Voltage (Voc) 23.0 V
Short-circuit Current (Isc) 11.4 A
Module Efficiency (ηm) 21.7%
Operating Temperature Range -40°C to +85°C
Maximum Series Fuse Rating 20 A
Maximum System Voltage 1000 V DC
Weight 9.2 kg
Dimensions (L × W × H) 1200 × 765 × 30 mm

🌡 Temperature Coefficients

Parameter Value
Nominal Operating Cell Temperature (NOCT) 45°C ±2
Voltage Temperature Coefficient (Voc) (α) -0.32% / °C
Current Temperature Coefficient (Isc) (β) +0.055% / °C
Power Temperature Coefficient (Pmax) (γ) -0.39% / °C

🛠 Mechanical Data

Parameter Value
Solar Cell Monocrystalline, 182 × 70 mm
Cell Arrangement 64 Cells (4 × 8 × 2)
Front Glass 3.2 mm Tempered Glass
Frame Anodized Aluminium
Maximum Static Snow Load (Front) 5400 Pa
Maximum Static Wind Load (Back) 2400 Pa
Junction Box IP68 Rated
Cables & Connectors As Per Requirement
